Yamaha XMV4140 4-channel 140W Power Amplifier

Efficient by Design

At the heart of the XMV4140 is Yamaha’s patent-pending output voltage-matching circuit, working in sync with its Class D amplifier technology to push operating efficiency beyond 90%. Automatic voltage switching ensures the amp draws only what’s needed lowering energy use while delivering consistently clear, powerful audio output. Paired with Power Factor Correction, the XMV4140 balances power delivery to reduce current draw without sacrificing sound performance, no bulky cables or circuit overloads required.

Versatile Impedance Handling

One of the standout features of the XMV4140 is its ability to drive low-impedance (4Ω/8Ω) and high-impedance (70V/100V) speaker systems at the same time. With 140W per channel at low impedance and 125W at high impedance, you get flexible output options without needing multiple amps or external transformers. Even better, you can assign 70V or 100V operation to any channel pair, eliminating the need for bridge-mode workarounds.

Need more power for larger speakers? Activate Double Power Mode to double the output on select channels. And with intelligent onboard protection covering overheating, overcurrent, and impedance mismatch the XMV4140 is ready to run nonstop, even in less-than-ideal conditions.

Smarter System Redundancy

Things can go wrong during live operation but the XMV4140 is built to handle interruptions gracefully. In Backup Mode, the amp automatically switches from digital to analog inputs if the digital feed is lost, then switches back when restored. In Override Mode, the system can switch inputs instantly ideal when a voice mic needs to cut in over background music or other content.

Each channel allows for individual input source selection and supports mixing digital and analog Euroblock connections, providing maximum installation flexibility.

Seamless Integration with YDIF and Yamaha Ecosystem

With built-in YDIF (Yamaha Digital InterFace) support, you can link the XMV4140 over standard Ethernet cabling ideal for integrating into larger audio networks. It’s fully compatible with Yamaha’s MTX and MRX Series processors, making it easy to configure and control your setup via the MTX-MRX Editor software or optional control interfaces like PV Touch, PV Control, and PV Amp Editor. Whether you’re managing a single venue or a multi-zone system, it all connects with clarity and control.

Key Features

• 4-channel amplifier ideal for commercial venues, hospitality, and large-scale AV installs
• 140W per channel at 4Ω/8Ω and 125W at 70V/100V, with support for simultaneous operation
• Class D design with output voltage matching for over 90% efficiency
• Power Factor Correction (PFC) ensures stable performance with reduced power consumption
• Double Power Mode for higher-output speaker configurations
• Automatic protection features guard against thermal overload, overcurrent, and impedance faults
• Backup Mode and Override Mode for intelligent input switching and failover
• Assignable input sources per channel (digital + analog Euroblock)
• YDIF-compatible for easy system linking and integration
• Works seamlessly with MTX/MRX processors and Yamaha control apps
• Fits in a standard 2U rackmount chassis
